224-310KW广西顶博发电机组制造:康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯来发电用发起机汽油条件性好: 高端的汽油操作模式，别具一格 的STC、ESTC 分等级操作模式，特色结构设计的缸筒边侧点燃室，髙压喷出汽油，加以雾化吸入，点燃加以。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯风能发电用打着机瞬态的性能出色: 无极限的打着机局部构思，积极配合康明斯显著的EFC体统，掌控精确高，为了响应周期快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯发电站用汽车发驱力升功效高: 整体布局设置省油的suv.外型设计合理安排，进行平稳性。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷智能机型 QSNT. QSK19. QSK38. QSK50拥有中国有非市政道路然后时候及美国Tier2. Tier 3尾气排放标准法律规范的标准。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零备件管理可求性好， 启驱动力执行及系统维护护肤连锁便利店，生产成本又。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

输出功率时间范围 Power Range   224-310KW形式 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L内部结构寸尺 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净性能 Dry Weight   940kg

224-310KW康明斯来发电用汽车发因素的共同点：表面积小， 减小比低， 集水管热空气采暖器，非常容易再启动，联通车截电压的选择。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

热车机材质	通用输出(kW)Prime Power	应急电机功率kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
